The REA MLV-2D is a matrix- and barcode verifi er which has been developed in conformance to international standards. The measurement uses defi ned angles distances and illuminations to achieve repeatable results and quality information.

The system uses a precise optical camera module with a CMOS Sensor type. The measuring area is shielded to avoid any ambient light infl uences. Reports are visualized by using the REA TransWin32 Software.
Communication is provided by the standardized,reliable and fast TCP/IP network communication.
Additional results are shown on the device display to provide a PC independent operation.

The REA Verifi er result allows a quick analysis why reading rates in applications are too low.

Options:
Four different camera modules with different fi eld of views and a selection of fi tting bottom plates are available. This allows adapting the verifi er to different code sizes.

Features:
■ contactfree measurement by a CMOS Camera
■ easy exchangeable camera modules to adapt to different code sizes
■ variable illumination (Angle is either 10° or 45°).Light source is either red or white light. All variations are software selectable included in each device
■ capable to measure DPM (direct parts marking) codes
■ fi eld of view is protected against ambient light infl uences
■ camera live image on the device display to allow an easy verifi er positioning
■ verifi cation according to ISO/IEC 15415 for printed matrix codes
■ verifi cation according to ISO/IEC TR 29158 / AIM DPM-1-2006 for direct parts marking matrix codes
■ verifi cation according to ISO/IEC 15416 or ANSI X3.182 for barcodes
■ verifi cation according to the GS1 General Specifi cations
■ verifi cation of GS1-128 data structures
■ verifi cation of optional parameters for optimizing the print process
■ multi language user interface and reports
■ easy to position

Supported symbologies:
■ Matrix Symbologies (2D): DataMatrix, GS1 DataMatrix, DPM-matrix codes, QR-code, MicroQR-code, more under development
■ Barcodes (1D):
EAN-13, UPC-A, UPC-E with/without ADD-ON,EAN-8, 2/5 Interleaved with/without check digit,ITF-14, DHL Express, code 39 with/without check digit, PZN-code, Code 32, Code 128, GS1-128 with/without data structure check, GS1 DataBar

■ Optional Symbologies (1D):
2/5 3 Bars, 2/5 5 Bars, 2/5 IATA, 2/5 Baggage,2/5 DHL Express, Code39 Full ASCII, Code93, MSI,Plessey, Code 128 UPU, Code 39 UPU, Code 39 HIBC,Code 128 HIBC, Codabar Monarch (18), LAETUS Pharmacode, LAETUS Mini Pharma code
